Thermal anemometer with smartphone - testo 405i

Details

Product Description

The testo 510i differential pressure measuring instrument, used in conjunction with a smartphone or tablet, is suitable for quick and easy measurement of gas flow pressure and static pressure, as well as pressure drops on fans and filters.

Turn your smartphone/tablet into a measuring instrument

Use your smartphone or tablet as a display: installed on a terminal device, the testo Smart App allows you to view testo 510i readings conveniently and carry out reliable timed and multi-point mean calculation. The App also includes a measurement menu for the pressure drop test. All measurement data can be displayed as a chart or in table form. The measurement data log can be emailed directly as a PDF or Excel file.

System requirements:

iOS 11 or later
Android 6.0 or later
Bluetooth 4.0

Technical Data

Temperature – NTC
Measuring range	-20 to +60 °C
Accuracy	±0.5 °C
Resolution	0.1 °C

Velocity – Hot wire
Measuring range	0 to 30 m/s
Accuracy	±(0.1 m/s + 5 % of mv) (0 to 2 m/s) ±(0.3 m/s + 5 % of mv) (2 to 15 m/s)
Resolution	0.01 m/s

Velocity – Hot wire

Measuring range

0 to 30 m/s

Accuracy

±(0.1 m/s + 5 % of mv) (0 to 2 m/s)

±(0.3 m/s + 5 % of mv) (2 to 15 m/s)

Resolution

0.01 m/s

General technical data
Weight	119.6 g
Dimensions	200 x 30 x 41 mm
Operating temperature	-20 to +50 °C
Product-/housing material	Plastic
System requirements	requires iOS 13.0 or newer; requires Android 8.0 or newer; requires mobile end device with Bluetooth 4.2
Product colour	black/orange
Battery life	15 h
Battery type	3 AAA micro batteries
Diameter probe shaft	12 mm
Diameter probe shaft tip	9 mm
Length probe shaft	400 mm
Storage temperature	-20 to +60 °C

Applications

Downloads

Datasheet Download Instruction Manual Download
