IR Temperature Gun – testo 830-T2

Model No: testo 830-T2Part No: 0560 8312

The testo 830-T2 infrared temperature gun equips you for efficient, non-contact surface temperature measurements for undertaking control measurements in trade and industry.
  1. Laser measurement point marker and large optics for exact measurement even at greater distances Fast recording of measurement values at two measurements per second
  2. Adjustable emissivity
  3. Two adjustable alarm limit values
  4. Good handling thanks to ergonomic “pistol design“
  5. Hold function and display of min./max. values
  6. Distance to measurement spot 12:1
  7. Measurement spot marking 2-point laser
  8. Contact external thermocouple (TC type K) for contact type Measurement

Details

The testo 830-T2 IR thermometer with laser measurement spot marker and 12:1 optics is suitable for non-contact surface temperature measurements in trade and industry.
Overview of the advantages offered by the testo 830-T2 IR thermometer :
With the testo 830-T2 IR thermometer, non-contact measurement of surface temperature is accurate and fast (2 measurements per second). To summarise, the IR thermometer offers the following advantages:
–    High resolution processor for utmost accuracy (resolution 0.1 °C)
–    12:1 optics for precise measurements even at medium distances
–    IR thermometer with 2-point laser measurement spot marker to target the measuring point
–    Two alarm limit values that can be defined as required
–    Visual and acoustic alarm if limit value exceeded
–    Min./max. value display and hold function (to record a measured value)
–    Convenient one-handed operation thanks to the ergonomic gun-style design
–    Clear, illuminated digital display
–    External probe connection for thermocouple temperature probes TC type K
The speed of the testo 830-T2 IR thermometer is also very impressive: it can carry out two measurements per second. This means you can undertake bigger measuring tasks quickly and efficiently.

In addition to infrared measurement, the testo 830-T2 infrared thermometer also offers the option of carrying out a contact measurement. Simply connect an optionally available TC type K temperature probe to the infrared measuring instrument. Testo offers a large selection of probes: e.g. a fast-action surface probe with sprung thermocouple strip, but also air probes or immersion/penetration probes (for liquids and pastes).

The IR thermometer emission level can be individually set. This allows you to adjust it precisely to the material of the surface being measured to achieve the best possible measurement results. For untreated surfaces with a low emission level, we recommend using an emission tape (optional) which makes the IR measurement significantly easier.

Technical Data

Temperature – TC Type K (NiCr-Ni)
Measuring range -30 to +400 °C
Accuracy ±1.5 °C (-20 to 0 °C),±2 °C (-30 to -20.1 °C),±1 °C or ±1 % of mv (Remaining Range)
Measuring rate 0.5 s
Infrared resolution 0.1 °C
General technical data
Dimensions 190 x 75 x 38 mm
Operating temperature -20 to +50 °C
Housing ABS
Battery type 9V block battery
Battery life 15 h
Storage temperature -40 to +70 °C
Weight 200 g

Applications

Downloads

 Datasheet Download  Instruction Manual Download
