Waterproof Foldable Thermometer – Testo 104

Model No: Testo 104 Part No: 0560 0104

The first folding waterproof food thermometer testo 104 allows you to carry out quick and easy spot checks during the production, storage and processing of food.
  1. Ideally suited for applications in the food sector
  2. Easy to operate Handy and small – fits in any trouser or jacket pocket
  3. Robust probe with narrow measurement tip
  4. Hygienic and easy-to-clean measurement tip
  5. Splash-proof according to IP55
  6. Certified according to EN 13485

Details

A robust metal folding joint, a rubber-coated anti-slip surface, a long and precise temperature sensor and waterproof into the bargain! The testo 104 waterproof food thermometer comes with a whole host of practical features and benefits for use in the food industry.

The food probe thermometer for the food industry Temperature checks play a vital role in quality assurance, cold chain documentation and hygiene regulations. The testo 104 waterproof food thermometer allows you to carry out quick and easy spot checks during the production, storage and processing of food. The food probe thermometer measures the core temperature of liquid, semi-solid and viscous media.

The sleek thermometer with rugged sensor tip leaves virtually no trace when inserted. The thermometer can also measure the core temperature of food when the probe has been folded out at an angle of only 30°. This allows you to carry out reliable checks in difficult-to-reach places.

The testo 104 is the only folding waterproof food thermometer which can be cleaned under running water after carrying out meassurements. The probe’s rugged metal joint allows it to be folded away and kept in its protective case until you need it again. And here’s another practical feature: the testo 104 waterproof food thermometer comes with a set of adhesive color strips which you can attachto the individual meters when more than one of the same model are being used.

The testo 104 food probe thermometer is not only HACCP compliant and EN 13485 certified but also splash water protected making it ideal for use in the food sector.

Technical Data

Temperature – TC Type K (NiCr-Ni)
Measuring range -50 to +250 °C
Accuracy ±1.0 °C (-50 to -30.1 °C),±0.5 °C (-30 to +99.9 °C),±1 % of mv (+100 to +250 °C)
Resolution 0.1 °C
Reaction time t99 = 10 s (measured in moving liquid)
General technical data
Dimensions 265 x 47 x 20 mm (Probe folded out),163 x 47 x 20 mm (probe folded away)
Operating temperature -20 to +60 °C
Product-/housing material ABS / ABS-PC fibre glass 10%
Protection class IP65
Product colour White
Length probe shaft 102 mm
Length probe shaft tip 32 mm
Diameter probe shaft 3 mm
Diameter probe shaft tip 2.3 mm
Measuring rate 0.5 s
Standards EN 13485
EU-/EG-guidelines 2004/108/EG
Battery Type 2 AAA micro batteries
Battery life 100 h (at +25 °C without display illumination)
Storage temperature -30 to +70 °C
Weight 165 g (incl. batteries)

Applications

Downloads

 Datasheet Download  Instruction Manual Download
